CORN HEADER WITH A HORIZONTAL CUTTER

Intended use: separation of corn cobs; stem harvesting and subsequent grinding.

rigid-design frame structure
tailor-made overload-release clutches for each contour hitch toolbar for any combine harvester model;
each cutting unit is equipped with pulling shafts 1 and two blades with a "butterfly" blade 2 for better stem chopping;
a stubble landward presser 3 .

rigid frame construction simplifies operation and maintenance of the reaper;
increased diameter high-capacity screw ensures uniform, uninterrupted, and gentle supply of the mass;
reaper chain drive reduces the reaper weight and makes it easy to operate;
aluminium gearboxes 4 significantly reduce the reaper weight and fuel costs;
safety clutches on each gearbox individually protect a cutting unit;
protective couplings of a rotor (shredder) protect the rotor from damage;
self-sharpening blades with carbide coating 2 ensure long service life of the cutting unit and a high-quality cut;
reaper boom angle adjuster ensures the adjustment of the approach angle and the cutting height;
stubble presser ensures reliable protection of the combine harvester tires 3 ;
plastic dividers ensure the ease of maintenance and good depreciation, as well as wear resistance;
the reaper can be adapted to any combine of imported and domestic production;
cutting height: from 8 cm* (subject to ideally prepared soil); this reduces the number of post-harvest operations. 3
